2) READING THE MAC ADDRESS & FIRMWARE
PROGRAM
1) Set the mode switch of the UP-600 to SRV position.
2) Display : [SRV MODE]
Select the [ 5. DIAGNOSTIC ] and press the ENTER key
Display : [ 5. DIAGNOSTIC ]
Select the [ TCP/IP ] and press the ENTER key
Display : [TCP/IP]
Select the [MAC ADDR&FIRM Ver. Read] and press the ENTER key
Display : [MAC ADD&FIRM Ver. Read]
3) Press the CANCEL key to exit .
SRV
1
2
3
4
5
READING
SETTING
IRC SET UP
DOWN LOAD
DIAGNOSTIC
UP-600/700 DIAG V1.0A
PRODUCT & TEST
RAM & ROM & SSP
CLOCK & KEY & SWITCH
SERIAL I/O
DISPLAY & PRINTER
MCR & DRAWER
TCP/IP
TCP/IP DIAG
SELF Check
LOOPBACK Check
MAC ADDR & FIRM Ver. Read
MAC ADDR & FIRM WRITE
DATA Trans. (MA)
DATA Trans. (SA)
MAC ADDR & FIRM Ver. READ
MAC ADDRESS:
08 00 1F XX YY ZZ
FIRMWARE VERSION:
27040
: Version number
XX YY ZZ
MAC Address : Hexadecimal number
