Sharp VC-V50S - Disassembly and Reassembly; Disassembly of Major Blocks

VC-V50S
VC-V80T
VC-V91T
3
4
3
7
8
9
1
10
5
6
2
MAIN FRAME
ANTENNA
TERMINAL
COVER
MECHANISM/
MAIN PWB
ASSEMBLY
TOP CABINET
TOP CABINET : Remove 3 screws 1.
FRONT PANEL : Remove 2 VR Knobs 2 at first(VC-
V91T). Remove 2 screws 3 and 7
clips 4.
MIC VR PWB : Remove 1 screw 5 and 1 FFC 6.
HOLDER
(VC-V91T)
2. DISASSEMBLY AND REASSEMBLY
2-1 DISASSEMBLY OF MAJOR BLOCKS
FRONT PANEL
XEBSD30P12000
XEPSD30P14XS0
XEBSD30P12000
XJPSD30P10WS0
XHPSD30P06WS0
MECHANISM/ : Remove 2 screws 7 and 2 screws 8.
MAIN PWB Remove 1 screw 9 from behind of the
ASSEMBLY main frame. Remove 1 connector 0.
Lift the antenna terminal cover and take
the assembly out of the main frame.
*MIC VR KNOB
*MIC VR PWB
HOLDER
*VC-V91T Only
