Sharp VC-V50S - Function of Major Mechanical Parts (Bottom View)

VC-V50S
VC-V80T
VC-V91T
7
FUNCTION OF MAJOR MECHANICAL PARTS (BOTTOM VIEW)
25
24
21
22
19
20
12
23
No. Function
No. Function
15 Drum ass’y
16 Loading motor
17 Drum drive motor
18 Take-up pole base ass’y
19 Slow brake lever
20 Master cam
21 Capstan D.D. motor
22 Reel belt
23 Clutch lever
24 Limiter pulley ass'y
25 Shifter
