XG-PH70X/XG-PH70X-N (1st. Edition)
19
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
D231 9NKH791570023 AF J Diode ES3D
D232 9NKH013070631 AG J Diode UGF10DCT
D233 9NKi003870123 AL J Diode MBRF2560CT
D234 9NKi003870123 AL J Diode MBRF2560CT
D235 9NKK850750023 AC J Diode 1N4148W
!
F151 9NK0805340702 AD J Fuse 4A 250V
HS101 9NK3343203702 N J Heat Sink for Q151, D152, D153
HS102 9NK3343203702 N J Heat Sink for CR151, D154
HS131 9NK3341072101 AE J Heat Sink for IC131
HS231 9NK3343203801 AK J Heat Sink for D232, D233, D334
HS232 9NK3343902300 AC J Heat Sink for IC231
!
IC101 9NK2633002311 AG J IC DAP008CR2
IC102 9NK2500008010 AE J IC LM7815
!
IC131 9NK2510325434 AP J IC TOP246YN
IC201 9NK2500004214 AC J IC TL431
IC231 9NK2500004214 AC J IC TL431
IC232 9NK2500300114 AY J IC TPS75501KC
IC280 9NK2500004214 AC J IC TL431
L131 9NK2921113712 AB J Bead
!
L151 9NK2817187480 AX J Inductor 597µH
!
L152 9NK2817130180 AP J Inductor 3.7µH
L201 9NK2816460810 AC J Inductor 2µH
L231 9NK2816460810 AC J Inductor 2µH
L232 9NK2816460810 AC J Inductor 2µH
L233 9NK2816310200 AC J Inductor 12µH
L234 9NK2816310200 AC J Inductor 12µH
L251 9NK2817185480 AF J Inductor 12.57µH
!
NTC151 9NK0911000116 AE J 10 (L)
!
NTC152 9NK0911000116 AE J 10 (L)
!
Q101 9NKP008040013 AL J FET 2SK3303
Q102 9NKN524800005 AC J Transistor MMBT5401L
!
Q151 9NKO070270010 AV J FET IRG4PC50WPBF
!
Q152 9NKP077450035 AT J FET SPW20N60S5
Q154 9NKN231010011 AC J Transistor 2SB562CTZ
Q200 9NKM522000405 AB J Transistor MMBT3904L
Q203 9NKN522000205 AB J Transistor MMBT3906L
!
Q251 9NKP501200305 AK J FET NTD4302T4G
!
Q252 9NKP501200305 AK J FET NTD4302T4G
Q282 9NKN522000205 AB J Transistor MMBT3906L
Q283 9NKM522000405 AB J Transistor MMBT3904L
R101A 9NK0313101000 AB J Resistor 100 1/4W Metal Oxide
R101B 9NK0313101000 AB J Resistor 100 1/4W Metal Oxide
R102 9NK0341588100 AB J Resistor 2.2k 1/8W Metal Oxide
R103 9NK0313333000 AB J Resistor 33k 1/4W Metal Oxide
R104 9NK0313333000 AB J Resistor 33k 1/4W Metal Oxide
R105 9NK0341026100 AB J Resistor 100 1/8W Metal Oxide
R106 9NK0341047100 AB J Resistor 2.7k 1/8W Metal Oxide
R107 9NK0343303100 AB J Resistor 30k 1/8W Metal Oxide
R108 9NK0133338022 AB J Resistor 3.3 2W
R109 9NK0341059100 AB J Resistor 10k 1/8W Metal Oxide
R110 9NK0341012100 AB J Resistor 10 1/8W Metal Oxide
R112 9NK0311202000 AB J Resistor 4.75k 1/4W Metal Oxide
R114 9NK0123100000 AB J Resistor 10 1/2W
R115A 9NK0401418004 AB J Resistor 649k 1/4W Metal Oxide
R115B 9NK0401418004 AB J Resistor 649k 1/4W Metal Oxide
R115C 9NK0401418004 AB J Resistor 649k 1/4W Metal Oxide
R116 9NK0910500216 AB J Resistor 5 , NTC/3A
R117 9NK0311113000 AB J Resistor 2k 1/4W Metal Oxide
R131A 9NK0393154600 AB J Resistor 150k 3/4W Metal Oxide
R131B 9NK0393154600 AB J Resistor 150k 3/4W Metal Oxide
R132 9NK0123100000 AB J Resistor 10 1/2W
R133A 9NK0311640000 AB J Resistor 715k 1/4W Metal Oxide
R133B 9NK0311640000 AB J Resistor 715k 1/4W Metal Oxide
R133C 9NK0311640000 AB J Resistor 715k 1/4W Metal Oxide
R134 9NK0393470600 AB J Resistor 47 3/4W Metal Oxide
R135 9NK0313000000 AB J Resistor 0 1/4W Metal Oxide
R136 9NK0341012100 AB J Resistor 10 1/8W Metal Oxide
R151 9NK0311578000 AB J Resistor 7.5 1/4W Metal Oxide
R152 9NK0311578000 AB J Resistor 7.5 1/4W Metal Oxide
R153 9NK0311113000 AB J Resistor 2k 1/4W Metal Oxide
R154 9NK0233079103 AC J
Resistor 0.07 7W
R155 9NK0233079103 AC J Resistor 0.07 7W
R156 9NK0311578000 AB J Resistor 7.5 1/4W Metal Oxide
R157 9NK0311026000 AB J Resistor 100 1/4W Metal Oxide
R158 9NK0311578000 AB J Resistor 7.5 1/4W Metal Oxide
R159 9NK0311113000 AB J Resistor 2k 1/4W Metal Oxide
R160A 9NK0311417000 AB J Resistor 46.4k 1/4W Metal Oxide
R160B 9NK0311417000 AB J Resistor 46.4k 1/4W Metal Oxide
R160C 9NK0311417000 AB J Resistor 46.4k 1/4W Metal Oxide
R160D 9NK0311417000 AB J Resistor 46.4k 1/4W Metal Oxide
R161A 9NK0311097000 AB J Resistor 261k 1/4W Metal Oxide
R161B 9NK0311097000 AB J Resistor 261k 1/4W Metal Oxide
R161C 9NK0311097000 AB J Resistor 261k 1/4W Metal Oxide
R163 9NK0143202400 AB J Resistor 2k 2W
[4] 9NK5600204367 (POWER Unit)
