XG-PH70X/XG-PH70X-N (1st. Edition)
2 – 1
XG-PH70X
Service Manual
CHAPTER 2. REMOVING OF MAJOR PARTS
[1] Removing the Lamp Unit
1. Remove the screw from the lamp cover and detach the lamp cover.
2. Remove the four screws from the lamp units and take out the lamp units.
1-1
1-2
Lamp Cover
Lamp Unit 2
Lamp Unit 1
Bottom Case
