Sharp XG-PH70X User Manual

XG-PH70X/XG-PH70X-N (1st. Edition)
1 – 1
XG-PH70X
Service Manual
CHAPTER 1. OPERATION MANUAL
[1] SPECIFICATIONS
Multimedia Projector
XG-PH70X (standard zoom lens attached)/XG-PH70X-N (no lens attached)
NTSC3.58/NTSC4.43/PAL/PAL-M/PAL-N/PAL-60/SECAM/
DTV480I /DTV480P/DTV540P/DTV576I /DTV576P/DTV720P/DTV1035I /DTV1080I
0.7" DLP chip x 1
No. of dots: 786,432 dots (1,024 [H] x 768 [V])
1.2 x electric zoom/focus lens, F1.8−F2.0, f = 25.6−31.3 mm (standard equipment with XG-PH70X)
260 W x 2
15-pin mini D-sub connector
Y: 1.0 Vp-p, sync negative, 75 Ω terminated
P
B: 0.7 Vp-p, 75 Ω terminated
P
R: 0.7 Vp-p, 75 Ω terminated
750 TV lines (DTV720P)
BNC connector
Y: 1.0 Vp-p, sync negative, 75 Ω terminated
P
B: 0.7 Vp-p, 75 Ω terminated
P
R: 0.7 Vp-p, 75 Ω terminated
15-pin mini D-sub connector, 5 BNC connector: RGB separate/composite sync (TTL)/sync
on green type analog input: 0Ð0.7 Vp-p, positive, 75 Ω terminated
Horizontal sync. signal: TTL level (positive/negative) or composite sync (Apple only)
Vertical sync. signal: Same as above
DVI connector (24-pin), RGB (digital), 250
− 1,000 mV, 50 Ω (Compatible with HDCP)
RCA connector: VIDEO, composite video, 1.0 Vp-p, sync negative, 75 Ω
terminated
4-pin mini DIN connector
Y (luminance signal): 1.0 Vp-p, sync negative, 75 Ω terminated
C (chrominance signal): Burst 0.286 Vp-p, 75 Ω terminated
φ3.5 mm stereo minijack, RCA terminal
0.5 Vrms, more than 22 kΩ
φ3.5 mm minijack
0.5 Vrms, less than 2.2 kΩ
9-pin D-sub connector
8-pin RJ-45 modular connector
12
− 230 MHz
43
− 200 Hz
15
− 126 kHz
3.0 W (stereo)
3.3 cm round x 2
AC 100
− 240 V
6.6 A (AC 100 V)
− 2.7 A (AC 240 V)
50/60 Hz
650 W (when "Eco Mode" is "OFF")/570 W (when "Eco Mode" is "ON") with AC 100 V
620 W (when "Eco Mode" is "OFF")/550 W (when "Eco Mode" is "ON") with AC 240 V
0.8 W (AC 1 00 V) − 1.1 W (AC 240 V) (When "Monitor Out" and "LAN/RS232C" are set to "Disable".)
2,440 BTU/hour (when "Eco Mode" is "OFF")/2,140 BTU/hour (when "Eco Mode" i s "ON")
with AC 100 V
2,330 BTU/hour (when "Eco Mode" is "OFF")/2,070 BTU/hour (when "Eco Mode" i s "ON")
with AC 240 V
41 F to 104 F (+5 C to +40 C)
− 4 F to 140 F ( − 20 C to +60 C)
Plastic
38 kHz
16
5
/32"x7
3
/32"x18
35
/64" (410 (W) x 180 (H) x 471 (D) mm) (main body only)
16
5
/32"x7
37
/64"x18
35
/64" (410 (W) x 192.1 (H) x 471 (D) mm) (including adjustment foot
and projecting parts)
XG-PH70X: 32.9 lbs. (14.9 kg)
XG-PH70X-N: 30.3 lbs. (13.7 kg)
Remote control, Power cord for U.S., Canada, etc., Power cord for Europe, except U.K.,
Power cord for U.K., Hong Kong and Singapore, Power cord for Australia, New Zealand and
Oceania, RGB cable
, Remote mouse receiver, Cap for the standard zoom lens, Projector
manual and technical reference CD-ROM, Operation manual
Product type
Model
Video system
Display device
Standard zoom lens
Projection lamp
Component input (INPUT 1)/
output (OUTPUT) signal
Horizontal resolution
Component input (INPUT 2)
signal
RGB input (INPUT 1/2)/output
(OUTPUT) signal
RGB digital input signal (INPUT 3)
Video input signal
(INPUT 4)
S-video input signal
(INPUT 5)
Audio input signal
Audio output signal
(AUDIO OUTPUT 1
− 5)
RS-232C terminal
LAN terminal
Pixel clock
Vertical frequency
Horizontal frequency
Audio output
Speaker system
Rated voltage
Input current
Rated frequency
Power consumption
Power consumption (standby)
Heat dissipation
Operating temperature
Storage temperature
Cabinet
I/R carrier frequency
Dimensions (approx.)
Weight (approx.)
Replacement parts
As a part of policy of continuous improvement, SHARP reserves the right to make design
and specification changes for product improvement without prior notice. The performance
specification figures indicated are nominal values of production units. There may be some
deviations from these values in individual units.
®
