XG-PH70X/XG-PH70X-N (1st. Edition)
39
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[18] CABINET AND MECHANICAL PARTS
1 9NK0990075400 CH N J Ballast Unit x2
2 9NK3100001000 AC J Screw, M3*0.5*10 AC-IN Socket x2
3 9NK3100132500 AD J Screw, M3*0.5*25 Lamp Blower L x2
4 9NK3100132500 AD J Screw, M3*0.5*25 Lamp Blower R x2
5 9NK3100132800 AB J Screw, M3*0.5*28 Blower Rod x3
6 9NK3100300800 AB J Screw, M3*0.5*8 Blower Bracket Rod x2
7 9NK3100300800 AB J Screw, M3*0.5*8 Sensor BD
8 9NK3100300800 AB J Screw, M3*0.5*8 Blower Bracket Lamp R x2
9 9NK3100300800 AB J Screw, M3*0.5*8 Handle Bracket2 x6
10 9NK3100300800 AB J Screw, M3*0.5*8 Blower Duct x3
11 9NK3100300800 AB J Screw, M3*0.5*8 IO PWBA x6
12 9NK3100300800 AB J Screw, M3*0.5*8 IO Bracket x4
13 9NK3100300800 AB J Screw, M3*0.5*8 FAN Bracket PWBA x2
14 9NK3100300800 AB J Screw, M3*0.5*8 Ballast Holder x4
15 9NK3100300800 AB J Screw, M3*0.5*8 POWER Unit PWBA x4
16 9NK3100300800 AB J Screw, M3*0.5*8 POWER Unit Channel Down x4
17 9NK3100300800 AB J Screw, M3*0.5*8 SPK Bracket x2
18 9NK3100300800 AB J Screw, M3*0.5*8 AUDIO Unit x4
19 9NK3100450600 AB J Screw, M3*0.5*6 POWER Unit Channel x4
20 9NK3100300800 AB J Screw, M3*0.5*8 ENG x4
21 9NK3100300800 AB J Screw, M3*0.5*8 PC IF Unit PWBA
22 9NK3100300800 AB J Screw, M3*0.5*8 FILTER Unit PWBA x4
23 9NK3100300800 AB J Screw, M3*0.5*8 TOP x7
24 9NK3100300800 AB J Screw, M3*0.5*8 ADJ x2
25 9NK3100300800 AB J Screw, M3*0.5*8 Bimetal x4
26 9NK3100300800 AB J Screw, M3*0.5*8 Handle Bracket3 x11
27 9NK3100300800 AB J Screw, M3*0.5*8 MB x5
28 9NK3100300800 AB J Screw, M3*0.5*8 Lamp Channel
29 9NK3100300800 AB J Screw, M3*0.5*8 PC IF Unit BD Bracket x2
30 9NK3100300800 AB J Screw, M3*0.5*8 Engine Support x5
31 9NK3100402000 AB J Screw, M3*0.5*20 FAN PWBA x8
32 9NK3102301200 AB J Screw, M4*0.7*12 Lens Shift x8
33 9NK3102322000 N J Screw, M4*0.7*20 Lens x3
34
9NK3109020700 AB J Screw, M4*0.7*8 AC-Socket Cable
35 9NK3105136100 AB J Screw, M2*0.4*1.7 Speaker x8
36 9NK3105220800 AB J Screw, M3*0.5*5 ADJ x6
37 9NK3105260800 AB J Screw, M2*0.4*5 Lamp Duct R x2
38 9NK3105260800 AB J Screw, M2*0.4*5 Lamp_Duct_L x2
39 9NK3105260800 AB J Screw, M2*0.4*5 Rod Duct
40 9NK3105260800 AB J Screw, M2*0.4*5 POWER Unit Duct x4
41 9NK3105260800 AB J Screw, M2*0.4*5 Lamp L Grill x4
42 9NK3105260800 AB J Screw, M2*0.4*5 Micro_SW x2
43 9NK3105263700 AB J Screw, M2*0.4*5 KEYPAD Unit x11
44 9NK3105302700 AB J Screw, M3*0.5*14 Lamp Channel x2
45 9NK3105302700 AB J Screw, M3*0.5*14 TOP x2
46 9NK3105302700 AB J Screw, M3*0.5*14 Lamp-Channel-Cover2
47 9NK3106150400 AB J Screw, M3.5*1*8 Handle Bracket1 x4
48 9NK3106150400 AB J Screw, M3.5*1*8 IR Sensor
49 9NK3106150400 AB J Screw, M3.5*1*8 Thermal Sensor
50 9NK3106150400 AB J Screw, M3.5*1*8 Chassis x11
51 9NK3106170600 AB J Screw, ɔ3*1.058*12 TOP x9
52 9NK3106390400 AB J Screw, M3*1.058*8 Lamp Channel x4
53 9NK3106390400 AB J Screw, M3*1.058*8 FILTER Unit Interlock
54 9NK3109172000 N J Screw, M2*0.4*3 Lens Trim
55 9NK3110260500 AB J Washer E-Ring Lamp Cover
56 9NK3110260500 AB J Washer E-Ring Handle Pin x2
57 9NK3110366300 AB J Washer PLAIN ADJ x2
59 9NK3264524800 N J Label ID ( for XG-PH70X)
59 9NK3264525300 N J Label ID ( for XG-PH70X-N)
60 9NK3262014900 N J Label Warning
61 9NK3202334400 AG J Label Warning
62 9NK3209227800 AK N J Label Fusaguna
63 9NK3205123400 N J Lamp Label
64 9NK3230038700 AC J Snap Bushing
65 9NK3240270800 AC J Blower Cushion x8
66 9NK3240707501 AG J Insulator x2
67
9NK3240738700 AH J Insulator
68 9NK3240984100 AP J Cushion Rubber for Fan
69 9NK3240988801 AN J Cushion SIRub for Fan x3
70 9NK3240990600 AK J Sponge Cushion x2
71 9NK3240997400 AE J Sponge
72 9NK3240997600 AH J Sponge
73 9NK3241171402 AT J Insulator
74 9NK3241175100 AP J Insulator
75 9NK3241175300 AQ J Insulator
77 9NK3241190701 AQ J Insulator x2
78 9NK3351276800 AD J Pin
79 9NK3797405001 BD J Cover IO Ass'y
80 9NK3390041701 AT J Lamp AIR Guide x2
81 9NK3390044000 AF J IR Print Unit Hmt
82 9NK3390128800 AF J Cover IR Back Unit
83 9NK3797405101 BN J Top Cabinet Ass'y
83-1 Not Available - - Wire Holder x3
83-2 Not Available - - Sponge x5
83-3 Not Available - - Sponge x3
