Sharp XL-UR5H

E-6
ENGLISH
8
XL-UR5H
Preparation for Use
System connections
75 OHMS
AC INPUT
FM
ANT
BEAT
CANCEL
AM
LOOP
RATED SPEAKER IMPEDANCE:
8 OHMS MIN
1
2
Left speaker
Right speaker
Speaker connection
(see page 7)
AM loop aerial
FM aerial
Make sure to unplug the AC power lead before any connections.
Aerial connection (see page 7)
AC power connection (see page 8)
Wall socket
(AC 230 V, 50 Hz)
