E-22
ENGLISH
8
XL-UR5H
USB/SD Memory Playback
Note:
To pause playback:
Press the USB/SD / button.
To remove SD memory device
Notes:
z SHARP will not be held liable for the loss of data whilst the SD
memory device is connected to the audio system.
z Files compressed in MP3 and / or WMA format can be played
back when connected to the SD terminal.
z This SD memory’s format support FAT 16 or FAT 32.
z SHARP cannot guarantee that all SD memory devices will work
on this audio system.
z This SD memory cannot be operated via SD hub.
z If “NO SONG” is displayed, it means “Copyright protected WMA
file” or “Not supported playback file” is selected.
z The SD terminal in this unit is not intended for a PC connection
but is used for music streaming with a SD memory device.
z The larger the capacity of the SD storage device, the longer it will
take for the data to be read.
z Some SD multi-reader devices may not work correctly with the SD
terminal on this unit.
z External storage devices cannot be played back using the SD
terminal on this unit.
2 Press the TUNING/FOLDER ( or ) button to select
desired playback folder.
z To start playback with folder mode, go to step 4.
z To change the playback folder, press the TUNING/FOLDER (
or ) button to select another folder.
z In case of playback in the folder mode, press the TUNING/
FOLDER ( or ) button, and the desired folder can be
selected even though it is in playback mode.
It will continue playback mode in the 1st track of the selected
folder.
3 Select desired track to be played back by pressing the
or button. Proceed to step 4.
4 Press the USB/SD / button. Playback will start and the
track name will be displayed.
z Press the MEMORY/DISP button (ID3 ON/OFF) to display Title,
Artist and Album name.
z ID3 ON - Title, Artist and Album name is displayed.
z ID3 OFF - Title, Artist and Album name is not displayed.
1 Press the STOP button on the remote control or button
on the main unit.
2 Remove SD memory device from the SD terminal.
