Sharp XV-Z9000E

10
Important
Information
Part Names
Projector
Numbers next to the part names refer to the main pages in this manual where the topic is explained.
Side and Rear View
14
13
14
15
4
4
13
Intake ventilative hole
Exhaust ventilative hole
16
Remote control sensor
16
AC socket
DC 12 V 200 mA
OUTPUT terminal
Intake ventilative hole
4
15
INPUT 5 COMPUTER-RGB port
(15-pin Mini D-sub)
INPUT 1 COMPONENT/
RGB terminals (RCA)
INPUT 2 COMPONENT/
RGB terminals (RCA)
Wired remote
control jack
VIDEO INPUT 4 terminal (RCA)
13
S-VIDEO INPUT 3 terminal
(4-pin Mini DIN)
DC 12V OUTPUT
RS-232C port
(9-pin D-sub)
