Shelly Wave i4 DC User Manual

13. Technical Specifications
Power supply AC
No
Power supply DC
5 - 24 V DC
Power consumption
< 0.3 W
Overload protection
No
Power measurement
No
Number of inputs
4
Distance
Up to 40 m indoors (131 ft.) (depends on local condition)
Z-Wave repeater:
Yes
CPU
Z-Wave S800
Z-Wave frequency band
868,4 MHz; 865,2 MHz; 869,0 MHz; 921,4 MHz; 908,4 MHz;
916 MHz; 919,8 MHz; 922,5 MHz; 919,7-921,7-923,7 MHz;
868,1 MHz; 920,9 MHz
Maximum radio frequency
power transmitted in frequency
band(s)
< 25 mW
Size (H x W x D)
37x42x16 ±0.5 mm / 1.46x1.65x0.63 ±0.02 in
Weight
17 g / 0.6 oz
Mounting
Wall box
Screw terminals max. torque
0.4 Nm / 3.5 lbin
Conductor cross section
0.5 to 1.5 mm² / 20 to 16 AWG
Conductor stripped length
5 to 6 mm / 0.20 to 0.24 in
Shell material
Plastic
Color
Yellow
Ambient temperature
-20°C to 40°C / -5°F to 105°F
Humidity
30 % to 70 % RH

Shelly Wave i4 DC Specifications

General

Brand	Shelly
Model	Wave i4 DC
Category	Controller
Language	English
