Section 9 Periodical inspections and services
15. Inspection and Replacement of Fuse
and Slow Blow Fuse
Remove the cover of the fuse and check the
fuse.
Stop the engine and check the slow blow fuse.
If the fuse blows out, replace with new one of
specified capacity.
16. Inspecting the Tire
① Inspection of Tire
Check the tires of the front and rear wheels for
proper air pressure. It can be visually checked as
illustrated below.
Standard air pressure
Tire size
Air pressure
kPa (kgf/cm
2
)
Front
wheel
21×11.00-10-4PR 118 (1.2)
Rear
wheel
21×11.00-10-4PR 118 (1.2)
Check the tire for damage or crack.
② Inspection of wheel fixing bolt
Check each wheel fixing bolt for looseness. If
looseness is noticed, retighten referring to the
values in the table below.
Wheel Tightening torque Nm (kgf·cm)
Front 81.3 ± 9 (810 ± 90)
Rear 81.3 ± 9 (810 ± 90)
17. Color of Exhaust Gas
When the engine is started, a small amount of
black exhaust gas is emitted but usually exhaust
gas is colorless.
Black: ····Imperfect combustion because of too
rich fuel
White: ···Engine oil is burning. When the air
temperature is low, exhaust gas may
look white because of steam.
If black or white exhaust gas is emitted without
load, subject the vehicle to service at a dealer.
