Section 9 Periodical inspections and services
18. Inspection and Adjustment of Brake
● Check the brake for correct operation. If
not, an accident may be caused.
Press the brake pedal and check for specified
allowance (5 – 10mm) and same functioning
on the right and left sides. If the allowance of
the pedal is not as specified, remove the step
cover and adjust with the cable from the rear
wheel traveling section. If adjustment cannot
be completed at this point, remove the rear
wheel and adjust the adjusting point on the
inside of the rear wheel. Check that the
parking brake is properly applied with the
parking brake lever.
Warning
