Shimano E6100 - 5.3.1.1 Battery charge level

Original User Guide | Pedelec Shimano Steps Version 1 EN-39
5.3.1.1 Battery charge level
1. Briey press the battery button in standby mode.
Display Description Battery charge level
100%

5 LEDs light up 100 – 84%

4 LEDs light up 83 – 68 %
50 %

3 LEDs light up 67 – 51 %

2 LEDs light up 50 – 34 %
0 %

1 LED lights up 33 – 17 %
0 %

1 LED ashes 17 – 0 %
5.3.1.2 Capacity
Capacity indicates the quantity of electric charge that a
battery can deliver or store. It is specied in ampere hours
(Ah). Even when used properly, capacity diminishes over
time due to chemical reactions (ageing). So it reduces
with every charging cycle for example. A battery also ages
slightly when it is not used.
A charging cycle is the complete charging of a battery from
0 to 100% capacity. It follows that not every charging
process equates to a charging cycle. For example, a charge
from 50 to 100% capacity is only half a charging cycle.
1. Press the battery button for ve seconds. The maximum available
capacity (state of health) of the battery will be displayed.
Display Description Battery charge level
100%

3 – 5 LEDs light up The battery has a capacity
of over 50%.
< 50%

0 – 2 LEDs light up The capacity of the battery
is below 50%.
The battery may need to be replaced when fewer than
3 LEDs light up. Discuss how to proceed with your cycle
dealer.
5.3.1.3 Sleep mode
To prevent a total discharge, the battery management
system switches the battery to Sleep mode. Your battery
reverts to Sleep mode after 48 hours (depending on charge
level).
To wake from Sleep mode
1. Press the battery button for one second. The following appears:
Display Description

   
The rst, second, third, fourth and fth LEDs come on in order and then
all go o.
2. The battery has now “woken up”.
