7.2 Charger
Display Description Cause Remedy
The red
LED ashes
continuously.
There is a
charging fault.
Unplug the charger from the
mains immediately. If the
problem reoccurs, a new
battery charger is required.
8. Torque settings
DANGER
Only use appropriate tools to tighten screws and bolts. Observe
thespeciedtorquesetting.Thecomponentmanufacturer'storque
settings take precedence (where available). Failure to comply can
result in screws/bolts becoming loose, tearing away or fracturing. If
that happens while you are riding the bike, components may come
o and you could have a severe crash. If screws are overtightened,
components can also be damaged. Tighten all screws and bolts
that are relevant for safety with a torque wrench. This indicates the
corresponding torque in newton metres (Nm).
If no values are shown on the component or component manuals, use the
torque settings from the following table.
Screwxing Thread Tightening torque (Nm)
Pedal 9/16 40
Front axle nut General 25 – 30
Rear axle nut
General
35 – 40
Ahead stem angle adjustment M6 8 – 10
Screwxing Thread Tightening torque (Nm)
Ahead stem steerer tube M5 / M6 / M7 M5: 5 / M6: 10 / M7: 14
Saddle clamp bottom M5 / M6 / M8 M5: 5 / M6: 10 / M8: 20
Saddle clamp top M5 / M6 / M7
/ M8
M5: 5.5 / M6: 5.5 / M7: 14 /
M8: 20
Rim brake shoe M6 10
Disc brake calliper, Shimano, IS and PM M6 6 – 8
Disc brake calliper, AVID, IS and PM M6 8 – 10
Disc brake calliper, Magura, IS and PM M6 6
Gear lever clamp M5 5
Brake lever clamp M5 Ref. manufacturer's spec.
Cassette xing ring N/A 30 – 40
Screw-on handlebar plugs M4 / M5 M4: 3 / M5: 5
Luggage rack M5 / M6 M5: 5 – 6 / M6: 8 – 10
