Shimano INTER 5E - Table of Contents

1
Introduction of INTER-5E
………………………………………………………………………………………………
2
Dealer's Manual
………………………………………………………………………………………………………………………
4
SG-C7000-5V, SG-C7000-5R, SG-C7000-5C, SG-C7000-5D
• INSTALLATION/REMOVAL
• ADJUSTMENT
• MAINTENANCE
SG-C7050-5V, SG-C7050-5R, SG-C7050-5C, SG-C7050-5D
• INSTALLATION
• CONNECTION OF THE ELECTRIC WIRES
• MAINTENANCE
Troubleshooting
………………………………………………………………………………………………………………………
49
Disassembly & Assembly
………………………………………………………………………………………………
53
Required Tools & Parts
Replacing the Internal Assembly
Disassembling the Internal Assembly
Assembling the Internal Assembly
Service Parts & Tools
…………………………………………………………………………………………………………
75
Cassette Joint
Measurement Tool
Motor unit
NEXUS non-turn washers
Hub dimensions
(Over Locknut Dimensions and Axle)
…………………………………
78
EV / Spare Parts List
………………………………………………………………………………………………………………
81
CONTENTS
