Driver unit
Ball retainer A
Right hand cone
Apply internal geared hub grease to the parts indicated with the following icon.
Assembling the Internal Assembly
1. Install the driver unit.
2. Install the ball retainer A.
3. When installing the right hand
cone, align the two serrations with
the grooves in the axle, as shown.
(Y-04130100)
NOTICE
•
Although there is white-colored and black-colored grease, the two types can be mixed during use.
