A
B
C
D EF
Required Tools & Parts
NOTICE
•
For internal assembly replacement, only tool “e” is necessary.
•
For disassembling/assembling the internal assembly, all tools (“a” through “f”) are necessary.
•
When assembling or disassembling the internal unit, use a new E-ring. The E-ring is not reusable once removed.
•
When disassembling/assembling the internal assembly, work will be easier if a shifting lever compatible with the cassette joint is connected.
A: Hammer
B: TL-C7001
C: TL-S702
D: Slotted Screwdriver
E: TL-7S20
Hub spanners 17 mm×22 mm (2 pcs.)
F: Cassette joint
CJ-C7000
