Dealer’s Manual (SG-C7000-5V / SG-C7000-5R / SG-C7000-5C / SG-C7000-5D)
Return to index page
Click here for the latest Dealer's Manual
3. Operate the shifting lever and recheck that the yellow setting lines are
aligned.
Operate the shifting lever again from step 1 to check.
4. Cut off the excess length of inner cable and then install the inner end
cap.
For 11-speed, after installing the inner end cap, slightly bend the inner cable outward
(toward the dropout) so that it does not touch the chain.
Inner end cap
15 - 20 mm
Inner end cap
25 - 30 mm
15 - 20 mm
Inner end cap
5-speed
