Adjust the position of the switch unit.
Slide the switch unit horizontally and vertically to adjust it.
If it is difficult to slide, loosen the unit position adjustment bolt.
To remove the switch unit, loosen the unit position adjustment bolt while pulling the main body of
the switch unit away from the brake lever. Since the thread of the unit position adjustment bolt is
cut off midway to prevent detachment, it is necessary to pull the main body of the switch unit away
from the brake lever.
Unit position adjustment bolt
5.
Secure the switch unit.
Unit position adjustment bolt
3 N·m
6.
Installation/removal
Installing the switch unit
30
