Wiring around the cockpit (clamp band type cycle
computer)
For model: SC-EN600
As an example, this section explains how to connect two switch units.
Secure the switch unit to the handlebar.
Combine the I-SPEC EV brake lever as indicated in the figure when performing installation.
4.
Be sure to attach dummy plugs to any unused E-TUBE ports.
Installation/removal
Wiring around the cockpit (clamp band type cycle computer)
33
