Cord band
EW-CB300 (EW-SD300 type)
Handlebar
Cycle computer
Wiring around the cockpit (bracket installation type
cycle computer)
For model: SC-EN610
As an example, this section explains how to connect two switch units.
Be sure to attach dummy plugs to any unused E-TUBE ports.
Installation/removal
Wiring around the cockpit (bracket installation type cycle computer)
39
