Gear shifting adjustment with the electronic gear
shifting unit [Adjust]
Gear shifting adjustment for the electronic shifting unit is performed from the cycle computer.
Replace the clamp band.
Remove the clamp band, and install a new clamp band.
Fixing screw
Clamp
band
0.6 N·m
Switch unit integrated type cycle computer
Clamp band
Fixing screw
0.6 N·m
Switch unit integrated type cycle
computer
Make sure to use the included fixing screws. Other screws may damage the cycle computer or have
insufficient holding force.
2.
Refer to the dealer's manual of the shifting unit first to confirm whether adjustment is required before
adjusting. Under normal conditions, performing unnecessary adjustment may worsen gear shifting
performance. Improper adjustment may cause gear engagement skipping, resulting in an accidental
fall.
Maintenance
Gear shifting adjustment with the electronic gear shifting unit [Adjust]
50
