Notation method for operations
Subsequent operations using the main body button of the cycle computer and switch unit are indicated using
the following notation. Refer to each user's manual for information on the main body button of the cycle
computer and switches of the switch unit.
Mount the bicycle to a maintenance stand or otherwise secure it in place so that the rear wheel can be
spun freely.
The adjustment range of [Adjust] differs depending on the shifting unit and gear position, as shown
below. This section uses screens from a rear derailleur model for explanation.
Shifting unit Gear position Adjustment range
Rear derailleur 12 37 steps (Initial position 0 ± 18 steps)
11 33 steps (Initial position 0 ± 16 steps)
10 31 steps (Initial position 0 ± 15 steps)
Internal geared hub 11, 8, 5 9 steps (Initial position 0 ± 4 steps)
Maintenance
Gear shifting adjustment with the electronic gear shifting unit [Adjust]
51
