Drive unit
Cycle computer
Switch unit
PC link cable
SM-PCE02
Drive unit setting backup function
To check the drive unit settings backed up to the cycle computer, export a PDF report from the E-TUBE PROJECT
[Unit log acquisition] menu. When exchanging the drive unit, send the report along with the drive unit to the
distributor from which the unit was purchased.
Maintenance alert
This notifies the user that the bicycle requires maintenance. An icon is displayed on the cycle computer screen
when the bicycle reaches the set odometer or date. You must connect to E-TUBE PROJECT to set maintenance
alerts. For details, refer to the user's manual for E-TUBE PROJECT.
If the PC link cable included with the SM-PCE02 is not the EW-SD300 type, use a conversion adapter
(EW-AD305) to connect the wire to the EW-SD300. The EW-SD300 type PC link cable can be purchased
as a service part.
Refer to the “ SHIMANO STEPS Dealer's Manual ” for information on the E-TUBE ports of the drive unit.
Connection and communication with devices
Drive unit setting backup function
48
