Right switch
Satellite system
ON/OFF switch
To drive unit
* For details on the satellite system ON/OFF switch, refer to the “ SHIMANO STEPS Special Battery Parts Dealer's
Manual .”
Installation/removal
Wiring around the cockpit (other cases)
44
