Menu Operation
prefuse time, arc power, arc time,
align, proof test, and so on.
The manual splicing operaiton is
provided. Automatic arc calibration
doesn’t work in this splice mode.
8
NZ
For splicing Non-zero
dispersion-shifted fiber (ITU-T G655).
The MFD is 9 to 10 um at wavelength
of 1550 nm.
User can edit every parameters of this
splice mode. Like prefuse power,
prefuse time, arc power, arc time,
align, proof test, and so on.
The manual splicing operaiton is
provided. Automatic arc calibration
doesn’t work in this splice mode.
9
MM1
For splicing Multi-mode fiber (ITU-T
G651). Core diameter: 50.0 to 62.5
um.
User can edit every parameters of this
splice mode. Like prefuse power,
prefuse time, arc power, arc time,
align, proof test, and so on.
The manual splicing operaiton is
provided. Automatic arc calibration
does not work in this mode.
10
AT1(SM)
Users can decide how small or big the
loss is. (0.1~15dB)
The manual splicing operaiton is
provided.
