Shini SAL-430 - Technical Specifications; Outer Dimensions

7(29)
1.3 Technical Specifications
1.3.1 Outer Dimensions
Picture 1-1: Outer Dimensions
Table 1-1:Specifications
Model SAL-430 SAL-460
Ver. B B
Motor Type
Inductive
Blower power (kW) (50/60Hz) 0.37 0.75
Conveying pipe dia(Inch) 1.25 1.5
*Conveying capacity(kg/hr, 50Hz/60Hz) 200/220 300/330
Hopper capacity (L) 3 6
Input voltage 3Φ,400VAC,50Hz
Material level control Microswitch
Cloth filter Standard
Auto-cleaning Standard
Dimensions
H(mm) 660 735
W(mm) 310 350
D(mm) 430 455
Weight (kg) 23 26
Note：1) For hopper inside polished ones, add "P" at model behind.
2)Test condition of conveying capacity: Plastic material of bulk density 0.65kg/L, dia. 3~5 mm,
vertical conveying height: 4m, horizontal conveying distance: 1m.V.
Mounting Base
Specifications
