20(29)
Picture 3‑4：European suction box
When SHD-E is mounted on the floor stand, suction box should be equipped, so
as to convey the dried plastic material conveniently. The installation of European
suction box and shut-off suction box is simple. Install them at bottom of the hopper,
point to the holes and tighten up the screws.
Picture 3‑5：Shut-off suction box
3.4.3 Blower Inlet Filter Installation
When dryers in the dust-contain environment or hot air requires high cleanliness, it
can option with AIF blower inlet filter.
Picture 3‑6：Right：AIF blower inlet filter
