11(43)
Model
Item/
Parameters
SIC-20A SIC-25A SIC-30A SIC-40A SIC-45A SIC-50A
Refrigerant
Capacity
1)1
kW 52 60 76 104 114 120
Kcal/hr 44,720 51,600 65,360 87,720 98,040 103,200
Compressor
output
power
(Hz)
kW 16.12 19.94 23.6 26.28 35.4 36.44
HP 20 25 30 40 45 50
Refrigerant
Weight (kg) 18 22 26 34 42 48
Control Mode Thermostatic expansion valve
Type R22
Evaporator Type Tube-in-shell style
Condenser
Type Tube-fin style
Blower power (kW)
0.8×2 1.1×2 1.5×2 1.1×3 1.5×3 1.5×4
Water Tank Capacity (L) 180 200 270 400 650
Water pump
2)
(50Hz)
Power (kW) 2.2/3/4 4/3/4 4/4/5.5
Pump flow (L/Min) 200/300/300 300/300/300 533/366/367
Pump pressure
(kgf/cm
2
)
2.5/3/4.2 2.7/3.4/4.3
Total Power (kW)
3)
19.92 22.62 31.3 39.66 44.95 46.44
Pipe
Coupling
(inch)
Cooling Water
Outlet
2 2
1
/
2
2
1
/
2
Cooling Water Inlet
2 2
1
/
2
2
1
/
2
Water Tank Outlet 1
Water Tank Port 1/2 1
Protective
Devices
Compressor Overload relay
pump Overload relay
Cooling Water
Circuit
High and low pressure switch/anti-freeze switch
Water Circuit Flow switch (optional) / water tank level sensor (optional) / bypass valve
Power(VAC)
4
）
3Φ,400V,AC 50HZ
Measures Exchange Kw=860 kcal/hr 1RT=3,024kcal/hr 10,000Btu/hr=2,520kcal/hr
We reserve the right to change
specifications without prior noice.
Note:
1) Refrigeration capacity is measured based on the flow 0.172 m
3
/ (h.k W) and the outlet temperature (7℃) of
chilled water under the environment temperature of 30℃.
2) Low pressure pump is for domestic and Southeast Asia export, customers can change for medium
pressure pumps (use P for short; e.g.: SIC-5A-P) or high pressure pumps (use HP for short; e.g.:
SIC-5A-HP), specific parameters in turn as shown above.
3) Pump power is included in total power.
4) Special orders of machine voltage can be acceptable according to customers’ requests.
