22(43)
3. Installation and Debugging
Attention！
Please read through this chapter carefully before installation, and install
according to the following order!
The air-cooled water chiller needs a good cooling environment, so install
the water chiller near the window with good air ventilation. If installing the
water chiller in the workshop, the ambient temperature should not exceed
35℃. Besides, it should use the ventilator to make a good air circulation or
use the ventilation pipe to discharge the hot air generated by the chiller to
the room; If installing the water chiller outdoors, it must cover the top of the
machine.
3.1 Installation Notices
1) Make sure that the voltage and frequency corresponds with the
requirements on manufacturer's name plate.
2) Connection cable and ground wire must abide by local rules and
regulations.
3) Use independent electrical wires and power switch, and the diameter of
electrical wire should not be smaller than that of the electric wire used in
control box.
4) Wiring connections should be firmly fixed.
5) The power of this series of water chiller is three phase five wire, the power
supply is connected to the power live wire, (N) is connected to the null wire
and (G) is connected to the earth wire.
6) Power supply:
7) Main power voltage and nameplate specified voltage: ± 5%
8) Main power frequency and nameplate specified voltage: ±2%
9) Install the pipe system according to the installation configuration diagram,
and use thermal insulation materials to preserve the heat of the cold water
pipe.
10) The diameter of the circulating pump pipe shall not be smaller than that of
the condenser pipe (The inlet and outlet piping system shall be installed
