26
Product code: 42580
3 CH
4 CH
8 CH
Function
Value
Setting
200–224
Program 9 (green color flow)
225–249
Program 10 (blue color flow)
250–255
Sound-controlled mode
7
ID Address
000–009
ID1–ID66
010–019
ID1
020–029
ID2
030–039
ID3
040–049
ID4
050–059
ID5
060–069
ID6
070–079
ID7
080–089
ID8
090–099
ID9
100–109
ID10
110–119
ID11
120–129
ID12
130–139
ID13
140–149
ID14
150–159
ID15
160–169
ID16
170–179
ID17
180–189
ID18
190–199
ID19
200–209
ID20
210
ID21
211
ID22
212
ID23
213
ID24
214
ID25
251
ID62
252
ID63
253
ID64
254
ID65
255
ID66
8
Fader Response
000–250
CH1, CH2, CH3, CH4 instant fader response
251–255
CH1, CH2, CH3, CH4 delayed fader response
Note:
● Make sure that the Master Dimmer channel is open in 4-CH and 8-CH mode in order to see the light
output.
● The Red channel (CH2) in 8-CH mode works only in combination when CH1 is open and CH6 is
closed.
● The Color Preset channel (CH2) in 8-CH mode works only in combination when CH1 is open and CH6
is set between 1-24.
● The Speed channel (CH2) in 8-CH mode works only in combination when CH6 is set between 25-249.
● The Sound Sensitivity channel (CH2) in 8-CH mode works only in combination when CH6 is set
between 250-255. Multiple devices used together do not function the same, when set to same value.
● The Color Programs channel (CH6) in 8-CH mode works only in combination when CH1 is open.
