Compact Par 7 Tri
Product code: 42580
DMX Channels
3 CH
4 CH
8 CH
Function
Value
Setting
1
1
Master Dimmer
000–255
From low to high intensity (0–100 %)
1
2
2
Red
(If CH6=0)
000–255
From low to high intensity (0–100 %)
2
Color Presets
(If CH6=1–24)
000
No function
001–008
Color 1
R 255; G 000; B 000
009–017
Color 2
R 255; G 050; B 000
018–026
Color 3
R 255; G 150; B 000
027–035
Color 4
R 255; G 255; B 000
036–044
Color 5
R 200; G 255; B 000
045–053
Color 6
R 100; G 255; B 000
054–062
Color 7
R 040; G 255; B 000
063–071
Color 8
R 000; G 255; B 000
072–080
Color 9
R 000; G 255; B 050
081–089
Color 10
R 000; G 255; B 150
090–098
Color 11
R 000; G 255; B 255
099–107
Color 12
R 000; G 150; B 255
108–116
Color 13
R 000; G 050; B 255
117–125
Color 14
R 000; G 000; B 255
126–134
Color 15
R 050; G 000; B 255
135–143
Color 16
R 150; G 000; B 250
144–152
Color 17
R 255; G 000; B 255
153–161
Color 18
R 220; G 000; B 050
162–170
Color 19
R 150; G 050; B 100
171–179
Color 20
R 050; G 180; B 220
180–188
Color 21
R 050; G 220; B 100
189–197
Color 22
R 050; G 220; B 000
198–206
Color 23
R 150; G 000; B 220
207–215
Color 24
R 000; G 180; B 220
216–224
Color 25
R 000; G 220; B 050
225–233
Color 26
R 220; G 100; B 050
234–242
Color 27
R 220; G 200; B 100
243–251
Color 28
R 255; G 200; B 150
252–255
Color 29
R 255; G 255; B 255
2
Program Speed
(If CH6=25–249)
000–255
Speed adjustment of the built-in chases, from slow
to fast
2
Sound sensitivity
(If CH6=250-255)
000–255
From low to high sensitivity
2
3
3
Green
000–255
From low to high intensity (0–100 %)
3
4
4
Blue
000–255
From low to high intensity (0–100 %)
5
Linear Strobe
000–009
No function
010–255
From low to high frequency
6
Color Programs
000
No function
001–024
Program 1 (29 static color presets via CH2)
025–049
Program 2 (7-color, color flow) R, RG, G, GB, B, RB,
RGB
050–074
Program 3 (3-color, color flow) R, G, B
075–099
Program 4 (7-color, color switch) R, RG, G, GB, B,
RB, RGB
100–124
Program 5 (3-color, color switch) R, G, B
125–149
Program 6 (fantasy change 1)
150–174
Program 7 (fantasy change 2)
175–199
Program 8 (red color flow)
