SHOWTEC Net-2 User Manual

20
Order code: 50816
Net-2 Install
Product Specifications
Model:
Showtec Net-2 Install
Power supply:
12–36 V DC, 500 mA or PoE (802.3af)
Power consumption:
6 W
Dimensions:
105 x 98 x 58 mm (LxWxH)
Weight:
0,18 kg
Operation and programming
DMX:
2 universes (IN and/or OUT)
Control modes:
Art-Net, sACN, TCP/IPv4, DMX-512-A
Ethernet speed:
10/100Base-T
Setup:
Control panel, web interface
Merging options:
HTP, LTP, Normal, Backup
DMX data refresh rate:
40 Hz default (adjustable 10–40 Hz)
Electro-mechanical properties
IP rating:
IP20
Display:
OLED
Data connection:
3-pin Phoenix terminal (maximum cable gauge: 1,5 mm
2
/
AWG: 12), RJ45
Power connection:
2-pin Phoenix terminal (maximum cable gauge: 1,5 mm
2
/
AWG: 12)
Housing:
UL94-V0 flame-retardant polycarbonate
Color:
Gray
Mounting:
35-mm DIN rail system
(DIN EN43880 form factor; DIN EN60715 rail system)
Mounting size:
6 TE
Operating temperature:
0–40 °C
Max. ambient temperature t
a
:
40 °C
Max. housing temperature t
B
:
70 °C
Minimum distance:
Min. distance from flammable surfaces:
0,5 m
Design and product specifications are subject to change without prior notice.
Website: www.Showtec.info
