SHOWTEC Phantom 75 LED Spot V4 - Channels

19
Ordercode: 40188
Phantom 75 LED Spot
14 Channels
Channel 1 – Horizontal movement (Pan)
Move the slider up, in order to move head horizontally (PAN).
Gradual head adjustment from one end of the slider to the other (0-255, 128-center).
The head can be turned by 540° and stopped at any position you wish.
Channel 2 – Vertical movement (Tilt)
Move the slider up, in order to move head vertically (TILT).
Gradual head adjustment from one end of the slider to the other (0-255, 128-center).
The head can be turned by 270° and stopped at any position you wish.
Channel 3 – Pan fine 16 bit
Channel 4 – Tilt fine 16 bit
Channel 5 – PAN/TILT Speed
0-255
From Max Speed (0) to Min. Speed (255)
Channel 6 – Color wheel
Linear color change following the movement of the slider. Between 128 - 255, the color wheel rotates
continuously (so-called “Rainbow” effect).
0-6
Open / White
7-13
Yellow
14-20
Pink
21-27
Green
28-34
Red
35-41
Light Blue
42-48
Light Green
49-55
Orange
56-63
Dark Blue
64-70
Split Color White / Yellow
71-77
Split Color Yellow / Pink
78-84
Split Color Pink / Green
85-91
Split Color Green / Red
92-98
Split Color Red / Light Blue
99-105
Split Color Light Blue / Light Green
106-112
Split Color Light Green / Orange
113-119
Split Color Orange / Dark Blue
120-127
Split Color Dark Blue / White
128-191
Clockwise rotation (CW) rainbow effect from slow to fast
192-255
Counterclockwise rotation (CCW) rainbow effect from slow to fast
Channel 7 – Shutter/Strobe (Dimmer must be open )
0-3
Close
4-7
Shutter open
8-76
Strobe effect, from slow to fast (0-10 flashes/sec.)
77-145
Pulse strobe effect from slow to fast
146-215
Random strobe effect, from slow to fast (0-10 flashes/sec.)
216-255
Shutter open
Channel 8 – Dimmer intensity
0-255
From dark to brightest
