Ordercode: 40188
Phantom 75 LED Spot
Description of the device
Features
The Phantom 75 LED Spot is a moving head with high output and great effects.
• Input voltage: 100-240V AC, 50/60Hz
• Power consumption: 170W
• Light source: 1 x 75W White LED
• Light output: 24500 Lux @ 1m. (at 17°)
• LED drive current: 16,5 A
• Dimmer: 0-100%
• Strobe: 0-20Hz
• Beam angle: 17° - 20° manual
• Focus: Motorized focus
• DMX control: via standard DMX controller
• DMX channels: 8, 14 channels
• 16 built-in programs selectable by DMX
• Built-in automatic programs + built-in sound-activated programs
• 8 automatic and 8 sound-to-light programs
• User-selectable Pan & Tilt ranges: 540° / 360° / 180°
• Reverse Pan / Tilt movement
• Special: Pan / Tilt movement blackout
• Pan 0º -- 540º, Tilt 0º -- 270º
• Pan/Tilt resolution: 16 bit
• Control: Stand alone, Sound-controlled, Master/Slave, DMX-512
• Color wheel with 8 dichroic-colors and white
• Color functions: Split colors, Rainbow-flow effect
• Gobo functions: Gobo-flow effect, Gobo shake
• Gobo inner diameter: 20 mm, Gobo outer diameter: 24 mm
• Rotating gobo wheel with 2 glass gobos, 5 metal gobos and open with Gobo Shake Function
• Rotation: Bi-directional
• Prism: 3-facet prism
• Housing: Black metal & flame-retardant plastic
• Connection: 3-pin XLR IN/OUT, IEC power connector IN
• Fuse: F3A/250V
• Dimensions: 338 x 247 x 390 mm (LxWxH)
• Weight: 11 kg
Frontside
Fig. 01
01) 1 x 75W White LED
02) LED display + menu buttons
