● Auto
● Manual
● Master/Slave
● DMX-512 (1CH, 2CH, 3CH, 10CH, 20CH)
One Sunstrip (Auto, Manual)
01) Fasten the effect light to a firm trussing. Leave at least 0,8 meter on all sides for air circulation.
02) Always use a safety cable (ordercode 70140 / 70141).
03) Plug the end of the electric mains power cord into a proper electric power supply socket.
04) When the Sunstrip is not connected with a DMX cable, it functions as a stand-alone device.
Please see pages 18–19 for more information about Auto mode and Manual mode.
Multiple Sunstrips (Master/Slave control)
01) Fasten the effect light onto firm trussing. Leave at least 0,8 meter on all sides for air circulation.
02) Always use a safety cable (ordercode 70140 / 70141).
03) Use a 3-pin/5-pin XLR cable to connect the Sunstrip.
04) Link the units as shown in fig. 03. Connect the first unit's DMX "out" socket with the second unit's "in"
socket, using a DMX signal cable. Repeat this process to link the second, third and fourth units.
You can use the same functions on the master device as described on page 18–19 (Auto mode,
Manual mode). This means that you can set your desired operation mode on the master device
and all slave devices will react the same as the master device.
Multiple Sunstrips (Master/Slave control)
