Description of the device
Features
The Sunstrip LED is the successor of the already popular Sunstrip Active. Thanks to Tungsten mode, the
Sunstrip LED works like conventional bulbs while it is still possible to operate it in Warm white, Cool white or
in a combination of both.
● Input voltage: 110–240 V AC, 50/60 Hz
● Power consumption: 120 W
● Light source: 10 x 14W (Warm/Cool Prolight Opto)
● Control modes: Auto, Manual, Master/Slave, DMX
● DMX channels: 1, 2, 3, 10, 20 channels
● OLED display for easy setup
● Control protocol: DMX-512
● Dimmer: 0–100 %
● Strobe: 0–20 Hz
● IP rating: IP20
● Power connector: Pro power connector IN/OUT
● Data connector: 3-pin/5-pin XLR IN/OUT
● Fuse: T2AL/250V
● Dimensions: 1085 x 146 x 166 mm (LxWxH) (incl. brackets)
● Weight: 7 kg
Note: Knowledge of DMX is required to fully utilize this unit.
Optional accessories
D7039 – Case for 12 x Sunstrip Active
D7240 – Case for 8 x Sunstrip Active (Premium Line)
D7510 – Case for 8 x Sunstrip Active
Front
