Basic Receiver Connections (Figure 10)
1. Connect the receiver output to the mixer or amplifier input, using a standard audio
cable with a female 3-pin XLR connector or
1
/
4
-inch phone plug.
2. If desired, plug a set of headphones into the headphone monitor output connec-
tor.
AC POWER
FIGURE 10
AUDIO MIXER
AMPLIFIER LOUDSPEAKERLOUDSPEAKER
HEADPHONES
