Pin Receiver 1
(Left)
Receiver 2
(Right)
Connection Connection
Type
Impedance Voltage
Range
17 Diversity B Analog Output 2 kΩ 1–4 V
18 Diversity A Analog Output 2 kΩ 1–4 V
19 Serial Clock Digital Input Not
Applicable
1–4 V
20 Serial Clock Digital Input Not
Applicable
1–4 V
21 Network
Interrupt
Digital Input Not
Applicable
1–4 V
22 Network
Interrupt
Digital Output/Busy Not
Applicable
1–4 V
23 Serial Data
Output
Digital Output Not
Applicable
1–4 V
24 Serial Data
Input
Digital Input Not
Applicable
1–4 V
25 Ground Ground Not
Applicable
0 V
