EQUIPMENT AND INSTALLATION
Equipment supplied for the standard system
The standard system is made up of -
• marking mechanism with integrated electronic controls
• power lead
• maintenance kit
Unpacking
Unless delivered by us, the marking equipment is delivered in its own packaging. This packaging
should be kept carefully in case the equipment needs to be returned under guarantee.
Carefully unpack the pre-packed sub-units
Installation
a) Fixing
o install the equipment on a rigid, stable surface
b) Power supply
o before connecting the marking machine to the power supply (230V or 115V) check
that it has been set to the right voltage; check the voltage marked on the fuse drawer
o if the voltage selected is not the right one -
remove the fuse drawer from the base of the power unit
switch over the power switch
change the fuses (2 AT at 230V and 4 AT at 115V)
put the unit together again
o Switch on the marking equipment using the On/Off (0/I)switch at the back of the unit.
o the SIC screen will appear after a few moments, the software will load and the
main menu window will appear. The monitor is now ready.
ALTHOUGH THE EQUIPMENT IS PROTECTED IN LINE
WITH CURRENT STANDARDS
THE ELECTRONICS MAY BE SENSITIVE TO EXTERNAL
INTERFERENCE
IT SHOULD BE INSTALLED USING A STANDARD CABLE
WARNING
AND PROTECTED FROM POSSIBLE RADIATION
NOTE7V1EC7P62P122US-R01.doc 7/46
