SICK AS30 Core - Troubleshooting; Possible errors during operation

7 Troubleshooting
en
LED indicator/fault pattern Cause Measures
Bar graph and edge LED
(y
ellow) indicator flash.
- Short-circuit / Overcurrent
- Sensor is not connected prop‐
erly
- Disconnect sensor from the
power network
- Check pin assignment
- Reconnect sensor
- Check the current at the
switching output
Bar graph and edge LED
indic
a
tor (yellow) and
teach-in (yellow) flash
Programmed contrast or con‐
trast difference is not sufficient
for stable contrast detection.
- Clean sensor
- Readjust the sensor
- Check the application condi‐
tions
- Restart teach process
- Increase contrast difference
(sensitivity)
7.1 Possible errors during operation
Table 4: Troubleshooting during operation
Display, error situation Cause Measure
No switching event any more
•
Dis
t
ance or angle to mater‐
ial not consistent
•
Sensor dirty
•
Clean sensor
•
Readjust sensor
•
Check parameter settings
•
Perform teach process
again
Position value does not corre‐
spond t
o the actual value
Sensing distance incorrect Reading direction not correct
Realign sensor
An edge is detected even
though there is no object in
the field of view
Sensor dirty Clean sensor
TROUBLESHOOTING 7
