10 Technical data
10.1 General data
Table 6: Technical data
Attribute Value
Type designation AS30-
EBM314I110Z
ZZ000C000Z
Z
Z
AS30-
EBM434I110Z
ZZ000C000ZZ
Z
AS30-
PBM314I110Z
ZZ000C000ZZ
Z
AS30-
PBM434I110Z
ZZ000C000ZZ
Z
Part number 1095581 1095582 1095583 1095584
Operating modes Edge guid‐
ance (default)
Object position
Edge guid‐
ance (default)
Object position
Edge guidance
Object position
(default)
Edge guidance
Object position
(default)
Principle of operation Proximity Proximity Proximity Proximity
Sensing distance 25 mm 100 mm 25 mm 100 mm
Working range 20 mm ...
30 mm
90 mm ...
110 mm
20 mm ...
30 mm
90 mm ...
110 mm
Reading field 30 mm 45 mm 30 mm 45 mm
Smallest detectable
ob
jec
t (MDO)
0.2 mm 1.2 mm 0.2 mm 1.2 mm
Light source LED, white LED, white LED, white LED, white
Wavelength 400 nm ...
700 nm
400 nm ...
700 nm
400 nm ...
700 nm
400 nm ...
700 nm
Light spot size 39 mm x
12.2 mm
62.4 mm x
12.8 mm
39 mm x
12.2 mm
62.4 mm x
12.8 mm
Linearity of position value ±2% ±2% ±2% ±2%
Repeatability ±0.2 mm ±0.2 mm ±0.2 mm ±0.2 mm
Resolution of the display
or output v
alue
0.1 mm 0.1 mm 0.1 mm 0.1 mm
Alignment aid IO-Link IO-Link IO-Link IO-Link
Teach-in function Edge, Area Edge, Area Edge, Area Edge, Area
Supply voltage 18 - 30 V DC
Ripple ≤5 V
1)
Power consumption < 3.1 W
2)
Switching output Push / pull
Switching output (volt‐
ag
e)
Push / pull:
High = VS - 3 V
Low ≤3 V
Analog output 4 mA ... 20 mA
Analog output resolution 12 bit
Output rate of analog out‐
put
1 ms
Output current I
ma
x.
< 100 mA
3)
Initialization time 0.48 s
Connection type Male connector M12, 5-pin
4)
Protection class III
TECHNICAL DATA 10
