5 Mounting
5.1 Overview of mounting procedure
•
Selecting and preparing the mounting location.
•
Mounting the device.
•
Align device towards object with bar code.
•
Connect device to data cable and supply cable.
•
Adjust the device.
WARNING
Risk of injury due to damage to the device
For reasons of safety, a device which is visibly damaged must not be operated or must
be immediately taken out of operation. Damage includes, for example:
•
Housing: Cracked or broken
•
Reading window lens: Cracked or broken
•
Device with connector: Over-rotation of the connector, cracks, or being torn from
the housing
•
Device with fixed cable: Damage to the cable outlet or cable itself
5.2 Scope of delivery
The delivery of the device includes the following components:
Table 4: CLV63x–CLV65x: scope of delivery
No. of
units
Component Notes
1 Device in the version ordered Without bracket.
IP65 standard housing:
Ethernet variant:
•
M12 female connector sealed with
tightly screwed on protective plugs
•
Without connecting cables.
IP69K protective housing:
Both M12 connections sealed with tightly
screwed on protective plug or cap.
Without connecting cables.
1 Multilingual safety notes in a printed doc‐
ument
Informs about the requirements for safe
use of the product.
The delivery of the device in the IP69K protective housing includes the following addi‐
tional components:
MOUNTING 5
8019588/129Z/2019-02-07 | SICK O P E R A T I N G I N S T R U C T I O N S | CLV63x, CLV64x, CLV65x
27
Subject to change without notice
