CLV63x CLV64x CLV65x
CAN Function: SICK CAN sensor network (master/slave, multiplexer/
server), (tracking CLV65x-x8300A)
Data transmis‐
sion rate:
20 kbit/s ... 1 Mbit/s
Protocol: CSN (SICK CAN sensor network), CANopen (CLV65x only)
PROFINET Function: PROFINET single port
PROFINET Dual Port optional over external fieldbus mod‐
ule CDF600-2
Data transmis‐
sion rate:
10/100 Mbit/s
EtherCAT® Optional via external fieldbus module CDF600
PROFIBUS Optional via external fieldbus module CDF600-2
DeviceNet Optional over external connection module CDM420 and
CMF fieldbus module
Digital switching
inputs
Opto-decoupled, V
in
= max. 32 V, reverse polarity pro‐
tected, can be wired via PNP output, adjustable
debounce time 0 ... 10,000 ms
Cable: 2 (“Sensor 1”, “Sensor 2”), optionally with 2 additional
inputs via CMC600 parameter memory module in the
connection module
1)
12-pin Ethernet: 1 (“Sensor 1”, “Sensor 2”), optionally with 2 additional
inputs via CMC600 parameter memory module in the
connection module
1)
17-pin Ethernet: 2 (“Sensor 1”, “Sensor 2”), optionally with 2 additional
inputs via CMC600 parameter memory module in the
CDB650 connection module
Digital switching
outputs
PNP, I
out
= max. 100 mA, short-circuit protected, pulse
duration adjustable (static, 10 ... 1,000 ms)
Management: 2 (“Result 1”, “Result 2”), optionally with 2 additional
outputs via CMC600 parameter memory module in the
connection module
1)
12-pin Ethernet: No output, optionally with 2 outputs via CMC600 para‐
meter memory module in the connection module
1)
17-pin Ethernet: 2 (“Result 1”, “Result 2”), optionally with 2 additional
outputs via CMC600 parameter memory module in the
connection module
1)
Reading pulse Start: Switching input (type-dependent), fieldbus input (type-
dependent), command, auto-pulse, CAN (type-depen‐
dent), free-running
Stop: Reading pulse source, switching input (type-dependent),
command, timer, event (e.g. Good Read)
Optical indicators 6 LEDs (Ready, Result, Laser, Data, CAN, LNK TX)
Bar graph display of percentage read rate (10 LEDs)
Acoustic indica‐
tor
Beeper, can be switched off, can be allocated function
for event status indication
Operating ele‐
ments
2 pushbuttons
Parameter mem‐
ory
Micro SD card (optional) or connection module
1)
with
CMC600
