Mount t
he sender and receiver such that a right-angled protective field is estab‐
lished, i.e., when mounted vertically at the same height. (2)
b
For minor adjustments when aligning, the sender and receiver can be adjusted
longitudinally in the brackets.
90˚
9
0˚
2
r
s
b
P
osition the brackets near the ends of the housing. For devices with a protective
field height >300mm, the distance between the bracket and the end of the
housing must not exceed 1/4 of the length of the housing. If the device is exposed
to strong vibrations during operation, mount the top bracket at a height where the
offset in the safety light curtain housing rests on the bracket. (3)
3
5 MOUN
TING
34
