IDM corded
© SICK AG · Germany · All rights reserved · Subject to change without notice
Data Formatter
• Scan “Formatter Control” and set the barcode symbology to “48”.
• Scan “1st Insertion” and set the identified position to “06”, then inserted characters to “09” (Hex
Code of TAB), “53” (Hex Code of S), “4E” (Hex Code of N).
• Scan “2nd Insertion” and set the identified position to “12”, then inserted character to “09”. At the
end, you must scan “FIN” (Finish) code to terminate this selection.
• Scan “3rd Insertion” and set the identified position to “16”, then inserted character to “09”. At the
end, you must scan “FIN” (Finish) code to terminate this selection.
Data Replacer
• Scan “Replacer Control” and set the barcode symbology to “48”.
• Scan “1st Replacement” and set the identified position to “00”, then replaced character to “41” (Hex
Code of A).
Data Organizer
• Scan “Organizer Control” and set the barcode symbology to “48”.
• Scan “1st Organization” and set the identified position to “16”, then set the data transmission to “0”
(forward).
• Scan “2nd Organization” and set the identified position to “17”, then set the data transmission to “1”
(backward).
• Scan “END” (Exit) to terminate the programming.
Important notice
The Condensed DataWizard will follow the preset working flow as below:
Verifier Formatter Replacer Organizer
Therefore when you set the identified position in the Data organizer, you must consider the inserted
data which you already set via Data Formatter.
