Symbology ID table (2D and Post codes)
IDM corded
© SICK AG · Germany · All rights reserved · Subject to change without notice
6.2 Symbology ID table (2D and Post codes)
Code Family Primary Format
SICK ID AIM ID
Hex Value Char. Code Char. Modified Char.
A0 b Q m
Data Matrix
c d m
X
6.3 Keyboard Function Code Table
No. ANSI ASCII Key Function Ctrl Output No. ANSI ASCII Key Function Ctrl Output
00 NUL 00H RESERVED Ctrl + @ 16 DLE 10H F7 Ctrl + P
01 SOH 01H CTRL (Left) Ctrl + A 17 DC1 11H F8 Ctrl + Q
02 STX 02H ALT (Left) Ctrl + B 18 DC2 12H F9 Ctrl + R
03 ETX 03H SHIFT Ctrl + C 19 DC3 13H F10 Ctrl + S
04 EOT 04H CAPS LOCK Ctrl + D 20 DC4 14H F11 Ctrl + T
05 ENQ 05H NUM LOCK Ctrl + E 21 NAK 15H F12 Ctrl + U
06 ACK 06H ESC Ctrl + F 22 SYN 16H INS (Insert) (Edit) Ctrl + V
07 BEL 07H F1 Ctrl + G 23 ETB 17H DEL (Delete) (Edit) Ctrl + W
08 BS 08H BACK SPACE Ctrl + H 24 CAN 18H HOME (Edit) Ctrl + X
09 HT 09H TAB Ctrl + I 25 EM 19H END (Edit) Ctrl + Y
10 LF 0AH F2 Ctrl + J 26 SUB 1AH PAGE UP (Edit) Ctrl + Z
11 VT 0BH F3 Ctrl + K 27 ESC 1BH PAGE DOWN (Edit) Ctrl + [
12 FF 0CH F4 Ctrl + L 28 FS 1CH UP (Edit) Ctrl + \
13 CR 0DH ENTER (CR) Ctrl + M 29 GS 1DH DOWN (Edit) Ctrl + ]
14 SO 0EH F5 Ctrl + N 30 RS 1EH LEFT (Edit) Ctrl + 6
15 SI 0FH F6 Ctrl + O 31 US 1FH RIGHT (Edit) see note
1)
1)
To emulate the keyboard function key input for user definable parameters, the user must configure actual
content using the Reserved ASCII 00 – 31 characters and also enable the “Function Key Emulation”.
Otherwise, the Ctrl output will be done by the scanner. Please refer to the above Keyboard Function Code
Table which is for IBM PC/XT/AT, PS/2, PS/VP, COMPAQ PC, HP Vectra PC, Notebook PC, APPLE and
PowerMac, and WYSE PC Enhanced or fully compatible machines. The last character in the Ctrl output column
varies for different countries.
