3.7.18 GS1 DataBar
PROGRAM
F_DEFAULT
Family Code Selection P.C. Parameter Selection Option Code
GS1 DataBar Settings
SS Disable GS1 DataBar (RSS-14) 0
SS Enable GS1 DataBar (RSS-14)  1
SS Disable GS1 DataBar Limited 2
SS Enable GS1 DataBar Limited  3
SS Disable GS1 DataBar Expanded 4
SS Enable GS1 DataBar Expanded  5
GS1 DataBar Min. Length
SS Default (04)  FIN
MS 01-74 (2 digits)
Only available for Expanded GS1 DataBar.
Scan 2 digits from the option code chart in the Appendix;
then the scanner will terminate this selection automatically.
GS1 DataBar Max.
Length
SS Default (74)  FIN
MS 01-74 (2 digits)
Only available for Expanded GS1 DataBar.
Scan 2 digits from the option code chart in the Appendix;
then the scanner will terminate this selection automatically.
