7.1.3 Option: “Freeze measured values”
As an alternative to the factory setting, the option “Freeze measured values” can be set
by Service during commissioning.
With this option, measured values are stopped and frozen during zero point adjustment
or reference point adjustment.
It takes some time after adjustment is completed until the measured values are acti‐
vated. The maintenance signal goes out and measuring operation can be continued
when the initial state is reached.
Measuring Mode
Premeasuring
Mode
Zero Point Adjustment/
Reference Point Adjustment
Measuring Mode
CO
2
approx. 5-7%
SO
2
/CO
2
ratio
SO
2
/CO
2
ratio
CO
2
Maintenance signal active
Adjustment starts.
Adjustment ends.
ANNEX 7
8026470/AE00/V1-0/2021-04 | SICK A D D E N D U M T O O P E R A T I N G I N S T R U C T I O N S | MARSIC300
23
Subject to change without notice
